IR3 Flame Detector, Explosion-Proof

Specifications

Standards explained

• EN 54-10Fire detection and fire alarm systems: flame detectors, point detectors

  Covers infrared and ultraviolet flame detectors for open areas, fuel storage and process plant where flames may occur without smoke.

  Reading the marking: Class 1, 2 or 3 sensitivity (class 1 detects a standard test fire at the greatest distance).

• ATEXEU ATEX Directive 2014/34/EU: equipment for potentially explosive atmospheres

  EU legal requirement for equipment used where flammable gas, vapour or dust may be present. Equipment must be certified for the zone and gas group of the area where it is used.

  Reading the marking: Ex symbol, Group II (surface industry), category 1 (Zone 0/20), 2 (Zone 1/21) or 3 (Zone 2/22), G gas or D dust. Protection concept, e.g. Ex ia (intrinsic safety), Ex d (flameproof), Ex e (increased safety). Gas group IIA, IIB, IIC (IIC most demanding, includes hydrogen). Temperature class T1-T6 (T6 lowest surface temperature).

• IECExIEC System for certification to standards relating to equipment for use in explosive atmospheres

  International certification scheme based on the IEC 60079 series; certificates can be checked on the IECEx online database. Many Middle East authorities accept IECEx or ATEX certification.

  Reading the marking: Uses the same Ex marking as ATEX, e.g. Ex ia IIC T4 Ga, with Equipment Protection Level Ga/Gb/Gc.

Overview

Downloads

• Technical datasheetPDF · 1.3 MB
