White vented climbing helmet on a wooden surface

Electrical-Insulating Safety Helmet

SKU: PPE-HD-103

Non-vented HDPE helmet rated for live-working electrical environments, with chin strap.

Standards

EN 50365 Class 0
EN 397 440 V AC

Available on requestPrice on request

Quantity

Specifications

Shell material	HDPE
Electrical rating	1000 V AC / 1500 V DC
Chin strap	Included
Standards	EN 50365 Class 0; EN 397 440 V AC

Standards explained

EN 50365Electrically insulating helmets for use on low-voltage installations
Covers helmets for live working on installations up to 1000 V AC or 1500 V DC. Specify it, rather than EN 397 440 V AC alone, when electricians may work on or near energised low-voltage equipment.
Reading the marking: Class 0 (the only class) with the double-triangle live-working symbol.
EN 397Industrial safety helmets
Sets requirements for top-impact shock absorption, penetration resistance and flame resistance of general industrial hard hats. It is the baseline European standard for construction, plant and site work.
Reading the marking: Optional marks show extra tested performance: -20 °C or -30 °C (very low temperature), +150 °C (very high temperature), 440 V AC (electrical insulation against brief accidental contact), LD (lateral deformation) and MM (molten metal splash).

Overview

Non-vented HDPE helmet rated for live-working electrical environments, with chin strap.

Specifications and certification details are confirmed in the quotation against the manufacturer's current datasheet. Contact our team for sizing, alternatives and documentation requirements.

Downloads

Technical datasheetPDF · 850 KB

Images may be representative of the product type; specifications and standards are indicative. Final specification, certification and suitability for your application are confirmed in our written quotation and the manufacturer’s instructions for use.
